Features: | Collapsible, Stackable, Half Drop Gate | External Size: | 1000L*800W*840H Mm |
---|---|---|---|
Wire Dia.: | 5.8mm | Mesh Grid: | 50*100mm |
Loading Capacity: | 1000kg | 20 Ft GP: | 240 Pcs |
40 Ft GP: | 506pcs | Raw Material: | Steel Q235 |
U-shaped Slot: | 5*2 | Surface Treatment: | Cold Galvanized, Hot Galvanized Is Available |
High Light: | folding wire mesh container,wire folding bulk containers |
Used Folding Wire Container and Eletronic Plated Basket for Warehouse
Standard Size Wire Container
Item No. | Specification | Wire Dia. | Mesh Gauge | Load Capacity | Weight | Feet Height | Load Qty 20GP | Load Qty 40Gp | Finish | |
External size(mm) | Internal size(mm) | (mm) | (mm) | (mm) | (kg)±2% | (mm) | (set) | (set) | ||
HG-B1 | 1000*800*840 | 950*750*700 | 5.8 | 50*50 | 1200 | 45 | 100 | 240 | 506 | Galvanized |
HG-B2 | 5.6 | 50*50 | 1000 | 43 | ||||||
HG-B3 | 5.3 | 50*50 | 800 | 40 | ||||||
HG-B4 | 4.8 | 50*50 | 600 | 35 | ||||||
HG-B5 | 5.8 | 50*100 | 1000 | 39.5 |
Features:
1. Foldable:
It’s cost-effective for shipping owning to the foldable design
2. Stackable:
Max stacking layer is 4 and it helps to save 4 times space for your warehouse.
3. Durable:
Longevity is about 8 years at normal temperature indoor using.
4. Multifunctional:
Auto Parts, Sanitary Hose, Used Shoes and Clothing, Vegetable, Fruit, All Components etc.
Optional Accessories
1. Corrugated plastic sheet: 4MM, 5MM, 6MM, 8MM, 10MM 5. Hingled Lids
2. Caster: Nylon, PP 6. Full Trop Gate
3. Forks Stirrups 7. Dividers
4. Forks Pockets 8. Traction
Half Drop Door
Collapsible wire baskets come standard with a half drop gate on the long side. The half drop gate
allows for easy ergonomic access to stored product. The drop gate also serves a purpose. It allows
these stacking wire baskets to becollapsible.
Drop gates can be dropped in half drop or full drop position on industrial wire mesh baskets. Drop
gates are secured by a safety latch that keeps gates closed and secured while basket is loaded and
while basket is in stacked position.
Application Cases
Quality Control
1. All our raw material is international standard Steel Q235.
2. There are over 200 experienced workers in workshop
3. Every worker passed our factory imployee criteria test.
4. Our quality control department checked the quality step by step before shipping.
